V-ZUG WarmingDrawer V4000 14

• Configuration
• Functions
• Documents
• Technical data

Selected product

Selected product

Article no.	3402600003

EAN code	7630029445952
Type	WDEA6V1C
Product category	Drawer
Standard width	60 cm
Standard height	14.4 cm
Front design	Black mirror glass
Handle	Push/pull

Display and operation

Display and operation

Controls	TouchControl

Kitchen drawer features

Kitchen drawer features

Sabbath mode	Yes
Stable telescopic fully extending runner	Yes
Drawer type	warming drawer
Number of temperature levels	6
Electronic temperature control	Yes
Glass heating plate	Yes
Stainless steel interior	Yes

Service and interfaces

Service and interfaces

Warranty	2 years

Also available with/as (*)

Also available with/as (*)

Front design	Platinum mirror glass, Fully integratable
Standard height	22 cm, 28.3 cm, 31.2 cm

(*) Not all combinations are available. Ask your retailer for advice.

• Favourites
• Plate warming
• Food warming
• Cup warming
• Yoghurt preparation
• Indoor light
• Proof dough
• Soft roasting
• Safety switch-off

Documents

Operating instructions

Installation guide

3D data (.3ds /.dwg / .dxf / .obj / .skp / .stp)

Brochure

Product image (high resolution)

Technical data

Dimensions

Dimensions

Niche height	144 mm
Niche width	600 mm
Niche depth	550 mm
Appliance height	142 mm
Appliance width	596 mm
Appliance depth	547 mm
Capacity for crockery	6
Capacity for plates	14
Volume	20 l
Empty weight	20 kg

Energy

Energy

Consumption when off	0 W
Type of connection (1)	220-240 V~
Frequency (1)	50/60 Hz
Connected loads (1)	0.81 kW
Fuse protection (1)	10 A
Plug type	AS/NZS_3112
Plug type B	BS1363/13A
Plug type C	CN CH1-10P
Plug type D	Schuko 16A
Plug type E	SII32
Connection cable	1.7 m

Product ID: WDV 4014 B
