V-ZUG Steamer V4000 45

• Configuration
• Functions
• Videos
• Documents
• Technical data
• Accessories

Selected product

Selected product

Article no.	2302600007

EAN code	7630029445129
Type	S4T-23026
Product category	Steam cooker
Standard width	60 cm
Standard height	45 cm
Front design	Black mirror glass
Handle	Black design handle
Cooking space	Stainless steel
Drawer	Without appliance drawer

Display and operation

Display and operation

Display	Full-colour graphic display, touchscreen
Controls	Touchscreen with CircleSlider
Number of languages in display	16
Languages in display	de-CH, de-DE, de-AT, fr-CH, fr-FR, it-CH, it-IT, en-GB, rm-CH, es-ES, nl-NL, ru-RU, uk-UA, tr-TR, he-IL, zh-CN
Number of lights	0
Temperature display	Target temperature

Steamer features

Steamer features

Number of insertion levels	4
Easy door cleaning	by disassembling the door
Time of day display	Yes
SoftClose	Yes
SoftOpen	Yes
Statistical data	Yes
Background images as display feature	Yes
Signal tone at target temperature	Yes
Residual heat usage	Yes
Cool door front	Yes
National cuisines for EasyCook	Yes
Personalisation	Yes
Personal app order	Yes
Removable door	Yes
Filter nutritional behaviour for EasyCook	Yes
Premium Swiss Quality	Yes
Electronic Steam System (ESS)	Yes
Panel height	80 mm
Steaming accurate to the degree	Yes
Climate sensor	Yes
Number of storable programmes	50
Cooking space volume	48 l
EcoStandby	Yes
Temperature in steam mode (min.)	30 C
Temperature in steam mode (max.)	100 C

Service and interfaces

Service and interfaces

Frequency range	2,4 GHz
WLAN as standard	802.11 b/g/n
ZUG-eye	Yes
Warranty	2 years
V-ZUG-Home	Yes
Interface	WLAN and Bluetooth

Accessories included

Accessories included

Product	Quantity
Durgol descaling agent (B28005)	1

Also available with/as (*)

Also available with/as (*)

Front design	Platinum mirror glass
Handle	Platinum design handle

(*) Not all combinations are available. Ask your retailer for advice.

• Steaming
• EasyCook
• Regeneration
• Favourites
• Hygiene
• Vacuisine
• Switch to summer time
• Food warming
• Wellness

Other settings

Other settings

User-controlled descaling	Yes

Documents

3D data (.3ds /.dwg / .dxf / .obj / .skp / .stp)

Operating instructions

Installation guide

Setup tips/EasyCook

Brochure

Product image (high resolution)

Product data sheet

Technical data

Dimensions

Dimensions

Niche height	450 mm
Max. niche height	450 mm
Niche width	560 mm
Max. niche width	568 mm
Niche depth	560 mm
Appliance height	454 mm
Max. appliance height	454 mm
Appliance width	597 mm
Appliance depth	569 mm
Depth of appliance when door is open	339 mm
Empty weight	34 kg

Energy

Energy

Consumption when off	0.5 W
Automatic shut-off consumption with network switched on	2 W
Type of connection (1)	220-240 V~
Frequency (1)	50 Hz
Connected loads (1)	3.7 kW
Fuse protection (1)	16 A
Plug type	Cable
Connection cable	1.8 m

Product ID: SV 4045B
