Selected product
Selected product
| Article no. |
5110800004 |
| EAN code |
7630029456682 |
| Predecessors article number |
5108600004 |
| Type |
CCO4T-51108 |
| Product category |
Refrigerator/freezer |
| Appliance type: Cooling |
Refrigerator/freezer combination |
| Standard width |
60 cm |
| Standard height |
177.8 cm |
| Front design |
Fully integratable |
| Handle |
without |
| Door hinge |
Right |
Display and operation
Display and operation
| Display |
Digital display |
| Controls |
TouchControl |
| Lighting |
LED |
| Number of lights |
3 |
Refrigerator features
Refrigerator features
| vzgpi_Gefrierkapazitaet2 |
5.7 l |
| Sabbath mode |
Yes |
| Premium Swiss Quality |
Yes |
| Total capacity |
282 l |
| Usable capacity of fridge compartment |
208 l |
| Usable capacity of freezer compartment |
73.7 l |
| Separate temperature control |
Yes |
| SoftClose |
Yes |
| Storage compartments in fridge compartment |
5 |
| Adjustable storage compartments in fridge compartment |
4 |
| Dividable glass shelves |
Yes |
| Containers in fridge compartment |
1 |
| Stable telescopic fully extending runner |
Yes |
| Door shelves and/or containers |
4 |
| Door compartments with lid or sliding door |
1 |
| Egg trays |
12 |
| Compartments in interior (freezer compartment) |
3 |
| Ice cube trays |
1 |
Service and interfaces
Service and interfaces
| WLAN as standard |
802.11 b/g/n |
| Warranty |
2 years |
| V-ZUG-Home |
Yes |
| Interface |
WLAN and Bluetooth |
- HygienePlus
- PartyCooling
- SilentPlus
- NoFrost
- ClickShelf
- MonoFridge
- ClimateControl
Other settings
Other settings
| Quick freezing |
Yes |
| Quick cooling |
Yes |
| Holiday function |
Yes |
Documents
Operating instructions
Installation guide
Energy label
Brochure
Product image (high resolution)
Product data sheet
Technical data
Dimensions
Dimensions
| Niche height |
1778 mm |
| Max. niche height |
1780 mm |
| Niche width |
550 mm |
| Max. niche width |
568 mm |
| Niche depth |
550 mm |
| Appliance height |
1776 mm |
| Max. appliance height |
1776 mm |
| Appliance width |
548 mm |
| Appliance depth |
545 mm |
| Depth of appliance when door is open |
1110 mm |
| Appliance depth including distance to wall |
580 mm |
| Max. compartment height in interior |
22.2 cm |
| Empty weight |
71.4 kg |
Energy
Energy
| Rated current |
1.0 A |
| Energy efficiency class of light source 1 |
F |
| vzgpi_Effizienz_Lichtquelle2 |
G |
| Energy efficiency rating |
C |
| Annual energy consumption |
146.0 kWh |
| Light sources must be replaced by a professional |
Yes |
| vzgpi_Lichtquellenverordnung |
Yes |
| Type of connection (1) |
220-240 V~ |
| Frequency (1) |
50 Hz |
| Connected loads (1) |
0.14 kW |
| Fuse protection (1) |
10 A |
| Plug type |
BS1363/13A |
| Connection cable |
2.3 m |
Additional data
Additional data
| Refrigerant |
R600a |
| Noise emission |
35 dB(A) |
| Noise emission class |
B |
| Climate class |
SN-T |
| Freezer volume |
5.7 kg/24h |
