General product information
| Product group output channels | Wine storage cabinet |
|---|---|
| GTIN | 9005382235850 |
Output and consumption
| Energy efficiency class | G |
|---|---|
| Energy consumption per year | 146.73 kWh/a |
| Noise level | 41 dB |
| Net capacity, total | 525 l |
| Gross capacity, total | 573 l |
| Refrigerant | R 600a |
| Voltage | 220-240 V ~ |
| Frequency | 50 Hz |
| Connection rating | 1.0 A |
| Noise level | 39 dB |
Dimensions and weight
| Product dimensions (H/W/D) | 192 / 70 / 74.2 cm |
|---|---|
| Weight (with packaging) | 108.00 kg |
| Weight (without packaging) | 100.00 kg |
Control and functions
| Control | Digital temperature display in the MagicEye |
|---|---|
| Control unit | Buttons |
| Malfunction: Warning signal | optical and acoustical |
| Temperature display | Wine compartment |
| Temperature setting range wine | +5C to +20C |
| Door open: Warning signal, wine storage compartment | audible |
| Child proofing |
Wine storage compartment
| Individual temperature zones | 1 |
|---|---|
| Temperature zones | 1 |
| Maximum number of 0.75 l Bordeaux bottles | 253 |
| Forced air cooling | |
| Lighting | LED light |
| dimmable | |
| permanently activated | |
| Number of storage shelves | 7 |
| of which can be pulled out on telescopic rails | 0 |
| of which wooden folding shelves | 0 |
| Storage shelf material, wine storage compartment | Wooden pull-out shelf |
| Activated charcoal filter | |
| Type of lock | fitted |
Design and features
| Side wall material | Stahl |
|---|---|
| Colour | Terra |
| Door/Cover material | Tinted insulated glass door |
| Door hinges | Right reversible |
| Door design | HardLine |
| Handle | Aluminium handle, solid with integrated opening mechanism |
Manuals and Documents
- Operating instructions
- Dimensional drawing
- Wine storage drawing
- UKCA-Certificate
Product ID: WKt5552
