Hansgrohe Raindance E & Ecostat E, shower system

Hansgrohe Raindance E & Ecostat E shower system: comfortable complete package

Lavishly equipped – the Raindance E & Ecostat E shower system from Hansgrohe comes with an elegant overhead shower, hand shower and thermostat.

Angular-round design

Visually, this sophisticated shower system impresses with its angular design and rounded edges in the all-time classic chrome design. The overhead shower impresses with proven functions such as AirPower and QuickClean, and the hand shower is even equipped with the Isiflex shower hose. No less than three spray modes pamper you in different ways. More function is not possible: Hansgrohe!

Product features

Raindance E 360 Air 1jet Overhead Shower with Shower Arm

• 1 spray mode: RainAir (lush soft, air enriched rain jet)
• soothing full, soft water drops enriched with air (AirPower)
• large shower with optimum water distribution (XXL Performance)
• limescale can be removed from the silicone naps with a simple wipe (QuickClean)
• overhead shower with pivot joint, rotation angle: 26 in every direction
• shower arm projection: 390 mm

Raindance Select E 120 3jet, EcoSmart Hand Shower with Isiflex Shower Hose and Fixfit Porter E Hose Connection

• 3 spray modes: Rain (powerful, pattering rain jet, ideal for washing hair), RainAir (lush soft, air enriched rain jet), Whirl (dynamic massage jet from 3 individual beams)
• change of spray mode at a push of a button (Select)
• soothing full, soft water drops enriched with air (AirPower)
• large shower with optimum water distribution (XXL Performance)
• separate internal water supply protects the chrome surface
• limescale can be removed from the silicone naps with a simple wipe (QuickClean)
• save water with maximum shower comfort (EcoSmart)
• maximum flow rate: 9 l/min
• rinsable dirt filter
• hose is kink resistant, flexible, easy-to-clean and with anti-twist protection
• shower hose: L: 1600 mm
• hose connection with internal plastic water conduit
• with non-return valve
• fixed position

Shower Select Concealed Thermostat for 2 Outlets

• suitable for 2 outlets
• switch between the outlets by turning
• constant water temperature even with fluctuating water pressure
• safety stop at 40C to protect against accidentally hot temperatures (scalding protection)
• maximum temperature can be pre-set at e.g. 42C (Safety Function)

iBox Universal Concealed Unit without Shut-Off

• 3 reductions 3/4″
• 1 plug 3/4″
• sealing flange
• adjustable clamping collar
• G 3/4″ threaded connection
• connection size: 1/2″ / 3/4″

Please note

• according to the manufacturer, suitable for instantaneous water heaters

SpecificationsItem number:27801000Series:Raindance Select EMaterial:metal/plasticColour:chromeMaterial overhead shower:metalShower hose length (mm):1600Hand shower length (mm):240Width of hand shower (mm):120Projection (mm):390Width of overhead shower (mm):360Depth of overhead shower (mm):190Type of fitting:thermostatsType of installation:concealedType of overhead shower assembly:wall-mountedShape:softcubeWater activation:by rotatingMax. water consumption of the hand shower at 3 bar (l/min):8.5Max. water consumption of the overhead shower at 3 bar (l/min):16.5Components:with tap fittingOverhead shower spray modes:1 jetHand shower spray modes:3 jetsBath filler:without bath fillerShippingContains:

concealed thermostat, concealed installation unit, overhead shower, shower arm, hand shower, shower hose, shower bracket, wall elbow, set of fittings

Packaging type:Parcel XLpdfTechnical drawingspdfAssembly instructionspdfAdvanced assembly instructionspdfCare instructions
