Hansgrohe Croma 220 Showerpipe bath

Product features

Hansgrohe Croma 220 Showerpipe Bath Set

consists of:

Hansgrohe Ecostat Comfort Thermostat

• maximum flow rate: bath filler: 20 litres per minute
• safety stop at 40C to protect against accidentally hot temperatures (scalding protection)
• adjustable hot water limitation
• outlets controlled via volume control/diverter and cannot be used simultaneously
• exposed design allows easy installation, all working parts are outside of the wall
• 1/2″ connection thread
• centre distance 150 mm12 mm

Hansgrohe Croma 220 Overhead Shower with Arm (art. no. 26464000)

• spray mode: RainAir (lush soft, enriched rain jet)
• soothing full, soft water jet enriched with air (AirPower)
• large shower with optimum water distribution (XXL Performance)
• maximum flow rate: RainAir (at 3 bar): 19 litres per minute
• operating pressure: min. 1 bar / max. 6 bar
• fully chrome-plated, metal spray face
• spray disc removeable for cleaning
• 1/2″ connection thread
• limescale can be removed from the silicone naps with a simple wipe (QuickClean)

Hansgrohe Croma 100 Vario Hand Shower (art. no. 28535000)

• 4 spray modes: Rain (powerful, pattering rain jet), normal spray (extensive, rich jet), Shampoo spray (powerful jet to wash your hair), Massage (konzentrierter, pulsierender Wasserstrahl)
• large shower with optimum water distribution (XXL Performance)
• spray mode adjustment by turning
• maximum flow rate (at 3 bar): 18 litres per minute
• operating pressure: min. 1 bar / max. 6 bar
• shower head size: 100 mm
• with internal water conduction
• rinseable dirt filter
• 1/2″ connection thread
• grey spray face
• limescale can be removed from the silicone naps with a simple wipe (QuickClean)

Hansgrohe Isiflex Shower Hose, 1.60 m (art. no. 28276000)

• high-quality metal effect shower hose
• anti-microbial coating to reduce the presence of bacteria
• shower hose length: 1.60 m
• pivot connectors prevent hose from tangling
• kink-protected
• larger inner diameter of 8 mm for higher flow rates
• conical nuts at both ends

Please note

• According to DIN 18534, areas behind fittings must be protected from moisture damage. Use special sealing tapes to ensure proper sealing. Please order separately. You will find suitable sealing tapes under accessories.

SpecificationsItem number:27223000Series:CromaMaterial:metal/plasticColour:chromeMaterial overhead shower:metalShower hose length (mm):1600Height (mm):1581Hand shower length (mm):237Diameter of hand shower (mm):100Projection (mm):398Diameter of overhead shower (mm):220Type of fitting:thermostatsType of installation:exposedType of overhead shower assembly:integratedShape:roundWater activation:by rotatingMax. water consumption of the bath inlet at 3 bar (l/min):20Max. water consumption of the hand shower at 3 bar (l/min):18Max. water consumption of the overhead shower at 3 bar (l/min):17Components:with tap fittingOverhead shower spray modes:1 jetHand shower spray modes:4 jetsBath filler:with bath fillerShippingContains:exposed shower thermostat, overhead shower, shower arm, shower rail, hand shower, shower hose, glider, set of fittingsPackaging type:Parcel pdfProduct data sheetpdfAssembly instructionspdfCare instructions
