AXOR Starck ShowerCollection trim set shower module 1/2″

Product features

AXOR Starck ShowerCollection Trim Set Shower Module

• 120 mm side shower
• jet types adjustable in five steps
• field of application: functions as overhead, shoulder or side shower
• 1 spray mode: normal spray (extensive, rich jet)
• flow rate normal spray (at 3 bar): 5.3 l/min
• operating pressure: minimum 1 bar / maximum 10 bar
• fully chrome-plated spray face
• connection thread: “
• basic set is recommended with a joined installation (10 mm distance)
• connection via a ” inner thread is possible in a freely arranged installation
• flow rate class: Z
• limescale can be removed from the silicon naps with a simple wipe (QuickClean)
• large shower with optimum water distribution (XXL Performance)

Please note

• please order concealed parts separately
• if installed as an overhead shower with several joint modules (1-9), the use of installation part no. 28470180 is recommended
• this item can also be installed as body spray consisting of three modules

SpecificationsItem number:28491000Series:Starck ShowerCollectionDesigner:Philippe StarckMaterial:metal/plasticColour:chromeWidth (mm):120Height (mm):29Depth (mm):120Type of fitting:overhead showersShape:square/rectangularMax. water consumption of the fitting at 3 bar (l/min):5.3Overhead shower spray modes:1 jetShippingPackaging type:ParcelpdfProduct data sheetpdfAssembly instructionspdfCare instructions
